CB360

Infrared human body temperature measurement module

The compact size, extremely light weight, universal interface, SDK for multi-platforms, fullframe temperature value output and many other high-performance features made CB360 the first choice for body temperature measurement integration. This device can quickly detect the human body’s temperature from 1.2 meters away. Featuring radiometric accuracy provides ±0.5°C temperature measurement accuracy. It can also support automatic over-temperature alarms, providing the public with a safe, convenient and efficient temperature measuring experience.


120x90 Resolution

2.3mm #F1.1 Focal Length

50°×38°FOV

20℃~50℃ Temperature range


(1)IR resolution 120×90

Full-frame radiometric info, output temperature value for all 10800 pixels

(2)Special for human body temperature measurement, excellent performance ±5℃ temperature measurement accuracy, 0.5M-1.2M temperature measurement distance

(3)Supermini, ultra-light, low power consumption

Wafer level packaging, weigh only 20g, power consumption≤150mW

(4)USB Type-C interface

Adopt USB Type-C male connector for external connection, strong versatility and easy integration

(5)Provide SDK for full platforms

Support Android / Linux / Windows platforms, wide applicability



Applications

Media Gallery

Technical Parameters

Model

CB360
